HEN Series Environmentally Sealed Limit Switches

Features: *Circuitry options from 1PST (one-pole single throw) circuit to 6PDT (six-pole double throw) circuits for position indication of different independent circuits or providing redundant circuit capabilities *Rugged stainless steel (300 Series) housing and bushing *All-metal drive train for consistent operating characteristics at high or low temperatures *Gold-bifurcated, gold-plated, or silver-alloy switch contacts for reliably controlling electrical loads

Installation dimensions:

Specifications: Rated Current/Voltage: Resistive 7A/28VDC Motel 4A/28VDC Inductive 4A/28VDC Service Life: Mechanically >25,000 (operations) Electrically >25,000 (operations) Operating Temperature:Std: -54 °C to 125 °C [-65 °F to 257 °F] High -65 °C to 315 °C [-85 °F to 600 °F] Vibration Resistance: Symbol 1, 10 g peak (10 -500 Hz) Shock Resistance: Symbol M (100g) per MIL-PRF-8805 Environmental Sealing: Symbol 5, hermetically seal per MIL-PRF-8805 Insulation Resistance: 500VDC; 1000 MOhms (min) Dielectric Strength: 1000V RMS; 500 μA (max)

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TYPE:HEN212-25-S View Details

TYPE:HEN211-25E-C6 View Details

TYPE:HEN211-25-U8 View Details
